2-Way Articulating Borescope for Android

QBH UW20-MD80U 2-Way Articulating Borescope for android

Introduction

This is a handheld borescope, can realize real-time & non-destructive inspection of small spaces; widely used in the inspection fildes of Automotive, Pipelines, Machinery & Equipment, Chemical etc.



Product Features

  1. Signal output mode :USB interface
  2. 2 way articulation snake camera ±180°, can detect hard-to-reach space,
  3. no dead ends
  4. Support: Android
  5. LED 4 level brightness adjustable
  6. Battery: The borescope can support the power for phone
  7. Download mobile APP, with taking photo and video functions
  8. Directly connect to OTG mobile phone, can review images
  9. Computer Connectable

Specifications

Snake tube

Model Image sensor Effective pixel Camera size View angle Camera light source Snake tube length
MD60U 1/9” CMOS 1280x720 Φ6.0mm 100˚ 0402 LED*8 0.8m
MD80U 1/5” CMOS 1600x1200 Φ8.0mm 80˚ 0603 LED*6 1.2m

Host

Focus distance Light source adjustable Power supply mode Waterproof level Working temperature
20mm-50mm Level 4 brightness adjustable OTG Android mobile phone IP67 -10~60ºC
